The Cape dory 25 is a 24.83ft masthead sloop designed by George Stadel and built in fiberglass by Cape Dory Yachts between 1973 and 1982.
845 units have been built.
The Cape dory 25 is a heavy sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Cape dory 25 | ||
| Length | 24.83 ft | ||
| Beam | 7.25 ft | ||
| Draft | 3 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.81 | ||
| Ballast / displ. | 42.50 % | ||
| Displ. / length | 306.19 | ||
| Comfort ratio | 22.02 | ||
| Capsize | 1.83 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 18 ft | ||
| Maximum draft | 3 ft | ||
| Displacement | 4000 lbs | ||
| Ballast | 1700 lbs | ||
| Hull speed | 5.69 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 264 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 124.11 sq.ft | ||
| Sail area main | 138 sq.ft | ||
| I | 27.58 ft | ||
| J | 9 ft | ||
| P | 24 ft | ||
| E | 11.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Cape Dory Yachts | ||
| Designer | George Stadel | ||
| First built | 1973 | ||
| Last built | 1982 | ||
| Number built | 845 |
