The Carbon 32 is a 32.0ft fractional sloop designed by Tim Kernan and built in carbon fiber or composite by Columbia Yachts since 2011.
The Carbon 32 is an ultralight sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Carbon 32 | ||
| Length | 32 ft | ||
| Beam | 10.13 ft | ||
| Draft | 2.17 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 30.59 | ||
| Ballast / displ. | 40.36 % | ||
| Displ. / length | 99.80 | ||
| Comfort ratio | 10.92 | ||
| Capsize | 2.48 |
Hull
| Hull type | Monohull lifting keel | ||
| Construction | Carbon fiber or composite | ||
| Waterline length | 27 ft | ||
| Maximum draft | 7.50 ft | ||
| Displacement | 4400 lbs | ||
| Ballast | 1776 lbs | ||
| Hull speed | 6.96 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 512 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 232.17 sq.ft | ||
| Sail area main | 282.53 sq.ft | ||
| I | 36.94 ft | ||
| J | 12.57 ft | ||
| P | 38 ft | ||
| E | 14.87 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Columbia Yachts | ||
| Designer | Tim Kernan | ||
| First built | 2011 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
