The Carter 30 is a 29.75ft masthead sloop designed by Richard (Dick) Carter and built in fiberglass by Northshore Yachts (UK) between 1972 and 1990.
300 units have been built.
The Carter 30 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Carter 30 | ||
| Length | 29.75 ft | ||
| Beam | 10.08 ft | ||
| Draft | 5.50 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.38 | ||
| Ballast / displ. | 40.77 % | ||
| Displ. / length | 267.85 | ||
| Comfort ratio | 20.77 | ||
| Capsize | 2.08 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 23 ft | ||
| Maximum draft | 5.50 ft | ||
| Displacement | 7300 lbs | ||
| Ballast | 2976 lbs | ||
| Hull speed | 6.43 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 384 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 229.69 sq.ft | ||
| Sail area main | 154.38 sq.ft | ||
| I | 37.50 ft | ||
| J | 12.25 ft | ||
| P | 32.50 ft | ||
| E | 9.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 12 HP | ||
| Fuel capacity | 15 gals |
Accommodations
| Water capacity | 30 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Northshore Yachts (UK) | ||
| Designer | Richard (Dick) Carter | ||
| First built | 1972 | ||
| Last built | 1990 | ||
| Number built | 300 |
