The Carter 33 is a 32.58ft masthead sloop designed by Richard (Dick) Carter and built in fiberglass by Olympic Marine (GREECE) since 1971.
200 units have been built.
The Carter 33 is a moderate weight sailboat which is a reasonably good performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a good water supply range.
Main features
| Model | Carter 33 | ||
| Length | 32.58 ft | ||
| Beam | 11 ft | ||
| Draft | 5.50 ft | ||
| Country | Greece (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.97 | ||
| Ballast / displ. | 38.13 % | ||
| Displ. / length | 263.68 | ||
| Comfort ratio | 18.21 | ||
| Capsize | 2.25 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 23.33 ft | ||
| Maximum draft | 5.50 ft | ||
| Displacement | 7500 lbs | ||
| Ballast | 2860 lbs | ||
| Hull speed | 6.47 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 405 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 239.85 sq.ft | ||
| Sail area main | 164.90 sq.ft | ||
| I | 39 ft | ||
| J | 12.30 ft | ||
| P | 34 ft | ||
| E | 9.70 ft |
Engine
| Nb engines | 1 | ||
| Total power | 10 HP | ||
| Fuel capacity | 11 gals |
Accommodations
| Water capacity | 106 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Olympic Marine (GREECE) | ||
| Designer | Richard (Dick) Carter | ||
| First built | 1971 | ||
| Last built | 0 | ?? | |
| Number built | 200 |
