The Catalina 387 is a 39.83ft masthead sloop designed by Gerry Douglas and built in fiberglass by Catalina Yachts since 2003.
The Catalina 387 is a moderate weight sailboat which is a reasonably good performer. It is stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a good water supply range.
Main features
| Model | Catalina 387 | ||
| Length | 39.83 ft | ||
| Beam | 12.34 ft | ||
| Draft | 7.15 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.24 | ||
| Ballast / displ. | 35.79 % | ||
| Displ. / length | 248.92 | ||
| Comfort ratio | 29.84 | ||
| Capsize | 1.85 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 32.42 ft | ||
| Maximum draft | 7.15 ft | ||
| Displacement | 19000 lbs | ||
| Ballast | 6800 lbs | ||
| Hull speed | 7.63 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 720 sq.ft | ||
| Air draft | 56 ft | ||
| Sail area fore | 373.50 sq.ft | ||
| Sail area main | 346.21 sq.ft | ||
| I | 50.92 ft | ||
| J | 14.67 ft | ||
| P | 44.16 ft | ||
| E | 15.68 ft |
Engine
| Nb engines | 1 | ||
| Total power | 40 HP | ||
| Fuel capacity | 37 gals |
Accommodations
| Water capacity | 102 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Catalina Yachts | ||
| Designer | Gerry Douglas | ||
| First built | 2003 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
