The Celestial 50 is a 50.75ft masthead ketch designed by Bryce Fuhriman and built in fiberglass by Xiamen Celestial Yacht Ltd since 1991.
The Celestial 50 is a moderate weight sailboat which is slightly under powered. It is stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is excellent. There is an excellent water supply range.
Main features
| Model | Celestial 50 | ||
| Length | 50.75 ft | ||
| Beam | 13.50 ft | ||
| Draft | 6.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.60 | ||
| Ballast / displ. | 37.04 % | ||
| Displ. / length | 217.74 | ||
| Comfort ratio | 35.90 | ||
| Capsize | 1.70 |
Hull
| Hull type | Monohull fin keel shoal draft | ||
| Construction | Fiberglass | ||
| Waterline length | 40.50 ft | ||
| Maximum draft | 6.50 ft | ||
| Displacement | 32400 lbs | ||
| Ballast | 12000 lbs | ||
| Hull speed | 8.53 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Ketch | ||
| Sail area (100%) | 0 sq.ft | ?? | |
| Air draft | 0 ft | ?? | |
| Sail area fore | 471.53 sq.ft | ||
| Sail area main | 452.25 sq.ft | ||
| I | 54.67 ft | ||
| J | 17.25 ft | ||
| P | 50.25 ft | ||
| E | 18 ft |
Engine
| Nb engines | 1 | ||
| Total power | 135 HP | ||
| Fuel capacity | 245 gals |
Accommodations
| Water capacity | 396 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Xiamen Celestial Yacht Ltd | ||
| Designer | Bryce Fuhriman | ||
| First built | 1991 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
