The Cheoy lee 43 ms is a 42.78ft masthead ketch designed by Robert Perry and built in fiberglass by Cheoy Lee Shipyard since 1981.
It accomodates 5 people in 3 cabins plus salon.
The Cheoy lee 43 ms is a heavy sailboat which is under powered. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a heavy bluewater cruising boat. The fuel capacity is excellent. There is an excellent water supply range.
Main features
| Model | Cheoy lee 43 ms | ||
| Length | 42.78 ft | ||
| Beam | 13.25 ft | ||
| Draft | 4.99 ft | ||
| Country | Hong Kong (Asia) | ||
| Estimated price | $ 127500 |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 12.26 | ||
| Ballast / displ. | 33.33 % | ||
| Displ. / length | 320.65 | ||
| Comfort ratio | 46.10 | ||
| Capsize | 1.61 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 36.88 ft | ||
| Maximum draft | 4.99 ft | ||
| Displacement | 36001.44 lbs | ||
| Ballast | 11993.13 lbs | ||
| Hull speed | 8.14 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Ketch | ||
| Sail area (100%) | 832.05 sq.ft | ||
| Air draft | 54 ft | ||
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 135 HP | ||
| Fuel capacity | 600 gals |
Accommodations
| Water capacity | 300 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 3 | ||
| Nb of berths | 5 | ||
| Nb heads | 2 |
Builder data
| Builder | Cheoy Lee Shipyard | ||
| Designer | Robert Perry | ||
| First built | 1981 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
