The Alize 20 jeanneau is a 19.85ft fractional sloop designed by E. G van de Stadt and built in fiberglass by Jeanneau (FRA) between 1963 and 1975.
350 units have been built.
The Alize 20 jeanneau is an ultralight sailboat which is a very high performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Alize 20 jeanneau | ||
| Length | 19.85 ft | ||
| Beam | 6.73 ft | ||
| Draft | 1.31 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 28.85 | ||
| Ballast / displ. | 28.93 % | ||
| Displ. / length | 75.43 | ||
| Comfort ratio | 6.50 | ||
| Capsize | 2.70 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 18.04 ft | ||
| Maximum draft | 3.94 ft | ||
| Displacement | 992 lbs | ||
| Ballast | 287 lbs | ||
| Hull speed | 5.69 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 179 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 75 sq.ft | ||
| Sail area main | 126 sq.ft | ||
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 4 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Jeanneau (FRA) | ||
| Designer | E. G van de Stadt | ||
| First built | 1963 | ||
| Last built | 1975 | ||
| Number built | 350 |
