The Compromis 777 is a 25.82ft masthead sloop designed by Frans Maas and built in fiberglass by C-Yachts/Compromis between 1977 and 2001.
472 units have been built.
The Compromis 777 is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. There is a very short water supply range.
Main features
| Model | Compromis 777 | ||
| Length | 25.82 ft | ||
| Beam | 9.12 ft | ||
| Draft | 4.10 ft | ||
| Country | The Nederlands (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.11 | ||
| Ballast / displ. | 43.48 % | ||
| Displ. / length | 217.91 | ||
| Comfort ratio | 17.92 | ||
| Capsize | 2.13 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 21.82 ft | ||
| Maximum draft | 4.10 ft | ||
| Displacement | 5071 lbs | ||
| Ballast | 2205 lbs | ||
| Hull speed | 6.26 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 278 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 29 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | C-Yachts/Compromis | ||
| Designer | Frans Maas | ||
| First built | 1977 | ||
| Last built | 2001 | ||
| Number built | 472 |
