The Concordia 40 is a 39.83ft masthead yawl designed by C. Raymond Hunt and built in wood planked by Abeking & Rasmussen between 1938 and 1966.
103 units have been built.
The Concordia 40 is a heavy sailboat which is slightly under powered. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat.
Main features
| Model | Concordia 40 | ||
| Length | 39.83 ft | ||
| Beam | 10.25 ft | ||
| Draft | 5.67 ft | ||
| Country | Germany (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.20 | ||
| Ballast / displ. | 42.78 % | ||
| Displ. / length | 347.13 | ||
| Comfort ratio | 39.29 | ||
| Capsize | 1.57 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Wood planked | ||
| Waterline length | 28.50 ft | ||
| Maximum draft | 5.67 ft | ||
| Displacement | 18000 lbs | ||
| Ballast | 7700 lbs | ||
| Hull speed | 7.15 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Yawl | ||
| Sail area (100%) | 650 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 288.56 sq.ft | ||
| Sail area main | 342 sq.ft | ||
| I | 42.75 ft | ||
| J | 13.50 ft | ||
| P | 38 ft | ||
| E | 18 ft |
Engine
| Nb engines | 1 | ||
| Total power | 30 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Abeking & Rasmussen | ||
| Designer | C. Raymond Hunt | ||
| First built | 1938 | ||
| Last built | 1966 | ||
| Number built | 103 |
