The Cyclades 393 Beneteau is a 39.27ft fractional sloop designed by Berret Racoupeau Yacht Design and built in fiberglass by Beneteau since 2007.
The Cyclades 393 Beneteau is a light sailboat which is a reasonably good performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a short water supply range.
Main features
| Model | Cyclades 393 Beneteau | ||
| Length | 39.27 ft | ||
| Beam | 12.96 ft | ||
| Draft | 6.23 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.41 | ||
| Ballast / displ. | 29.53 % | ||
| Displ. / length | 162.87 | ||
| Comfort ratio | 21.98 | ||
| Capsize | 2.08 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 35 ft | ||
| Maximum draft | 6.23 ft | ||
| Displacement | 15642 lbs | ||
| Ballast | 4619 lbs | ||
| Hull speed | 7.93 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 639 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 309.62 sq.ft | ||
| Sail area main | 329.19 sq.ft | ||
| I | 45.70 ft | ||
| J | 13.55 ft | ||
| P | 43.63 ft | ||
| E | 15.09 ft |
Engine
| Nb engines | 1 | ||
| Total power | 40 HP | ||
| Fuel capacity | 58 gals |
Accommodations
| Water capacity | 87 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Beneteau | ||
| Designer | Berret Racoupeau Yacht Design | ||
| First built | 2007 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
