The Diva 35 is a 35.4ft fractional sloop designed by Bernt Lindquist and built in carbon fiber or composite by Fabola Boats (SWE) between 1983 and 1993.
355 units have been built.
The Diva 35 is a light sailboat which is a high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat. The fuel capacity is originally small.
Main features
| Model | Diva 35 | ||
| Length | 35.40 ft | ||
| Beam | 10.80 ft | ||
| Draft | 6 ft | ||
| Country | Sweden (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 21.81 | ||
| Ballast / displ. | 44.81 % | ||
| Displ. / length | 157.76 | ||
| Comfort ratio | 18.25 | ||
| Capsize | 2.10 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Carbon fiber or composite | ||
| Waterline length | 29.10 ft | ||
| Maximum draft | 6 ft | ||
| Displacement | 8708 lbs | ||
| Ballast | 3902 lbs | ||
| Hull speed | 7.23 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 575 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 246.32 sq.ft | ||
| Sail area main | 329.19 sq.ft | ||
| I | 40.58 ft | ||
| J | 12.14 ft | ||
| P | 43.63 ft | ||
| E | 15.09 ft |
Engine
| Nb engines | 1 | ||
| Total power | 18 HP | ||
| Fuel capacity | 48 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Fabola Boats (SWE) | ||
| Designer | Bernt Lindquist | ||
| First built | 1983 | ||
| Last built | 1993 | ||
| Number built | 355 |
