The Dockrell 27 is a 27.0ft cutter designed by Ian Anderson and built in fiberglass by Dockrell Yachts Ltd. since 1979.
The Dockrell 27 is a heavy sailboat which is under powered. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Dockrell 27 | ||
| Length | 27 ft | ||
| Beam | 8 ft | ||
| Draft | 3 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 13.77 | ||
| Ballast / displ. | 45.71 % | ||
| Displ. / length | 337.44 | ||
| Comfort ratio | 29.73 | ||
| Capsize | 1.68 |
Hull
| Hull type | Monohull long keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 21 ft | ||
| Maximum draft | 3 ft | ||
| Displacement | 7000 lbs | ||
| Ballast | 3200 lbs | ||
| Hull speed | 6.14 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 314 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 9 gals |
Accommodations
| Water capacity | 28 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Dockrell Yachts Ltd. | ||
| Designer | Ian Anderson | ||
| First built | 1979 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
