The Electra pearson is a 22.5ft masthead sloop designed by Carl Alberg and built in fiberglass by Pearson Yachts between 1960 and 1965.
350 units have been built.
The Electra pearson is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Electra pearson | ||
| Length | 22.50 ft | ||
| Beam | 7 ft | ||
| Draft | 3 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.58 | ||
| Ballast / displ. | 43.30 % | ||
| Displ. / length | 284.99 | ||
| Comfort ratio | 18.78 | ||
| Capsize | 1.94 |
Hull
| Hull type | Monohull fin keel | ||
| Construction | Fiberglass | ||
| Waterline length | 16.75 ft | ||
| Maximum draft | 3 ft | ||
| Displacement | 3000 lbs | ||
| Ballast | 1299 lbs | ||
| Hull speed | 5.48 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 228 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 112.63 sq.ft | ||
| Sail area main | 115 sq.ft | ||
| I | 26.50 ft | ||
| J | 8.50 ft | ||
| P | 23 ft | ||
| E | 10 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Pearson Yachts | ||
| Designer | Carl Alberg | ||
| First built | 1960 | ||
| Last built | 1965 | ||
| Number built | 350 |
