The Andrews 28 is a 28.0ft fractional sloop designed by Alan Andrews and built in fiberglass by Sylvana Yachts Inc. between 2007 and 2010.
4 units have been built.
The Andrews 28 is an ultralight sailboat which is a very high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Andrews 28 | ||
| Length | 28 ft | ||
| Beam | 9.82 ft | ||
| Draft | 2.50 ft | ||
| Country | Canada (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 27.41 | ||
| Ballast / displ. | 34.40 % | ||
| Displ. / length | 98.05 | ||
| Comfort ratio | 10.46 | ||
| Capsize | 2.53 |
Hull
| Hull type | Monohull lifting keel | ||
| Construction | Fiberglass | ||
| Waterline length | 25.75 ft | ||
| Maximum draft | 7 ft | ||
| Displacement | 3750 lbs | ||
| Ballast | 1290 lbs | ||
| Hull speed | 6.80 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 412 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 178.31 sq.ft | ||
| Sail area main | 234 sq.ft | ||
| I | 32.42 ft | ||
| J | 11 ft | ||
| P | 36 ft | ||
| E | 13 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Sylvana Yachts Inc. | ||
| Designer | Alan Andrews | ||
| First built | 2007 | ||
| Last built | 2010 | ||
| Number built | 4 |
