The Espace 620 jeanneau is a 20.34ft masthead sloop designed by Jeanneau and built in fiberglass by Jeanneau (FRA) between 1983 and 1986.
30 units have been built.
The Espace 620 jeanneau is a moderate weight sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Espace 620 jeanneau | ||
| Length | 20.34 ft | ||
| Beam | 8.20 ft | ||
| Draft | 3.61 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.45 | ||
| Ballast / displ. | 37.49 % | ||
| Displ. / length | 209.10 | ||
| Comfort ratio | 13.35 | ||
| Capsize | 2.37 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 17.81 ft | ||
| Maximum draft | 3.61 ft | ||
| Displacement | 2646 lbs | ||
| Ballast | 992 lbs | ||
| Hull speed | 5.66 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 232 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 125.28 sq.ft | ||
| Sail area main | 107.18 sq.ft | ||
| I | 28.80 ft | ||
| J | 8.70 ft | ||
| P | 23.30 ft | ||
| E | 9.20 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Jeanneau (FRA) | ||
| Designer | Jeanneau | ||
| First built | 1983 | ||
| Last built | 1986 | ||
| Number built | 30 |
