The Essence 33 is a 33.23ft masthead sloop designed by Hoek Design and built in carbon fiber or composite since 2010.
The Essence 33 is a light sailboat which is a very high performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Essence 33 | ||
| Length | 33.23 ft | ||
| Beam | 8.86 ft | ||
| Draft | 6.40 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 26.02 | ||
| Ballast / displ. | 30.91 % | ||
| Displ. / length | 162.09 | ||
| Comfort ratio | 18.39 | ||
| Capsize | 1.95 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Carbon fiber or composite | ||
| Waterline length | 25.56 ft | ||
| Maximum draft | 6.40 ft | ||
| Displacement | 6063 lbs | ||
| Ballast | 1874 lbs | ||
| Hull speed | 6.77 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 539 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 287.79 sq.ft | ||
| Sail area main | 250.93 sq.ft | ||
| I | 39.86 ft | ||
| J | 14.44 ft | ||
| P | 36.42 ft | ||
| E | 13.78 ft |
Engine
| Nb engines | 1 | ||
| Total power | 13 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Hoek Design | ||
| First built | 2010 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
