The Fales 32 navigator is a 31.67ft cutter designed by William Crealock/Charles F. Street and built in fiberglass since 1974.
8 units have been built.
The Fales 32 navigator is a heavy sailboat which is under powered. It is stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is average. There is a good water supply range.
Main features
| Model | Fales 32 navigator | ||
| Length | 31.67 ft | ||
| Beam | 11.17 ft | ||
| Draft | 3.50 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 10.66 | ||
| Ballast / displ. | 35.29 % | ||
| Displ. / length | 307.35 | ||
| Comfort ratio | 35.33 | ||
| Capsize | 1.74 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 29.12 ft | ||
| Maximum draft | 3.50 ft | ||
| Displacement | 17000 lbs | ||
| Ballast | 6000 lbs | ||
| Hull speed | 7.23 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 439 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 226.13 sq.ft | ||
| Sail area main | 208.69 sq.ft | ||
| I | 33.50 ft | ||
| J | 13.50 ft | ||
| P | 39.75 ft | ||
| E | 10.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 86 gals |
Accommodations
| Water capacity | 100 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | William Crealock/Charles F. Street | ||
| First built | 1974 | ||
| Last built | 0 | ?? | |
| Number built | 8 |
