The First 47.7 Beneteau is a 47.01ft fractional sloop designed by Bruce Farr and built in fiberglass by Beneteau since 2000.
The First 47.7 Beneteau is a light sailboat which is a good performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a good water supply range.
Main features
| Model | First 47.7 Beneteau | ||
| Length | 47.01 ft | ||
| Beam | 14.76 ft | ||
| Draft | 7.58 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.23 | ||
| Ballast / displ. | 33.31 % | ||
| Displ. / length | 160.32 | ||
| Comfort ratio | 25.28 | ||
| Capsize | 2.01 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 41.34 ft | ||
| Maximum draft | 7.58 ft | ||
| Displacement | 25353.13 lbs | ||
| Ballast | 8443.69 lbs | ||
| Hull speed | 8.61 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 1033.01 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 482.76 sq.ft | ||
| Sail area main | 550.47 sq.ft | ||
| I | 56.59 ft | ||
| J | 17.06 ft | ||
| P | 52.03 ft | ||
| E | 21.16 ft |
Engine
| Nb engines | 1 | ||
| Total power | 75 HP | ||
| Fuel capacity | 66 gals |
Accommodations
| Water capacity | 185 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Beneteau | ||
| Designer | Bruce Farr | ||
| First built | 2000 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
