The Freedom 45 cc is a 45.0ft fractional sloop (free standing) designed by Gary Mull and built in fiberglass by Freedom Yachts since 1987.
The Freedom 45 cc is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Freedom 45 cc | ||
| Length | 45 ft | ||
| Beam | 13.50 ft | ||
| Draft | 4.92 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.52 | ||
| Ballast / displ. | 41.32 % | ||
| Displ. / length | 252.15 | ||
| Comfort ratio | 29.54 | ||
| Capsize | 1.90 |
Hull
| Hull type | Monohull wing keel | ||
| Construction | Fiberglass | ||
| Waterline length | 34.40 ft | ||
| Maximum draft | 4.92 ft | ||
| Displacement | 22992 lbs | ||
| Ballast | 9500 lbs | ||
| Hull speed | 7.86 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop (Free standing) | ||
| Sail area (100%) | 731 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 265.92 sq.ft | ||
| Sail area main | 465.55 sq.ft | ||
| I | 38.40 ft | ||
| J | 13.85 ft | ||
| P | 50.33 ft | ||
| E | 18.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 66 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Freedom Yachts | ||
| Designer | Gary Mull | ||
| First built | 1987 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
