The Frisco flyer iii is a 25.08ft masthead sloop designed by Tord Sunden/Cheoy Lee and built in fiberglass by Cheoy Lee Shipyard since 1964.
The Frisco flyer iii is a heavy sailboat which is slightly under powered. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Frisco flyer iii | ||
| Length | 25.08 ft | ||
| Beam | 7.25 ft | ||
| Draft | 3.92 ft | ||
| Country | Hong Kong (Asia) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.66 | ||
| Ballast / displ. | 45.45 % | ||
| Displ. / length | 331.14 | ||
| Comfort ratio | 28.67 | ||
| Capsize | 1.65 |
Hull
| Hull type | Monohull long keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 19.50 ft | ||
| Maximum draft | 3.92 ft | ||
| Displacement | 5500 lbs | ||
| Ballast | 2500 lbs | ||
| Hull speed | 5.92 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 304 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Cheoy Lee Shipyard | ||
| Designer | Tord Sunden/Cheoy Lee | ||
| First built | 1964 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
