The Gib Sea 20 is a 19.85ft masthead sloop designed by Michel Joubert and built in fiberglass by Gib'sea/Gibert Marine (FRA) between 1975 and 1980.
260 units have been built.
The Gib Sea 20 is a moderate weight sailboat which is a high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Gib Sea 20 | ||
| Length | 19.85 ft | ||
| Beam | 7.38 ft | ||
| Draft | 3.28 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 21.63 | ||
| Ballast / displ. | 34.30 % | ||
| Displ. / length | 220.71 | ||
| Comfort ratio | 14.12 | ||
| Capsize | 2.23 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 16.73 ft | ||
| Maximum draft | 3.28 ft | ||
| Displacement | 2314.85 lbs | ||
| Ballast | 793.66 lbs | ||
| Hull speed | 5.48 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 236.05 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Gib'sea/Gibert Marine (FRA) | ||
| Designer | Michel Joubert | ||
| First built | 1975 | ||
| Last built | 1980 | ||
| Number built | 260 |
