The Grand soleil 45 frers is a 45.73ft masthead sloop designed by German Frers and built in fiberglass by Grand Soleil (Cantiere del Pardo) since 1988.
The Grand soleil 45 frers is a moderate weight sailboat which is a reasonably good performer. It is stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a good water supply range.
Main features
| Model | Grand soleil 45 frers | ||
| Length | 45.73 ft | ||
| Beam | 13.62 ft | ||
| Draft | 7.22 ft | ||
| Country | Italy (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.95 | ||
| Ballast / displ. | 39.09 % | ||
| Displ. / length | 239.34 | ||
| Comfort ratio | 29.93 | ||
| Capsize | 1.89 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 35.63 ft | ||
| Maximum draft | 7.22 ft | ||
| Displacement | 24250 lbs | ||
| Ballast | 9479 lbs | ||
| Hull speed | 8 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 936 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 510.95 sq.ft | ||
| Sail area main | 425.02 sq.ft | ||
| I | 58.73 ft | ||
| J | 17.40 ft | ||
| P | 52.15 ft | ||
| E | 16.30 ft |
Engine
| Nb engines | 1 | ||
| Total power | 62 HP | ||
| Fuel capacity | 55 gals |
Accommodations
| Water capacity | 106 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Grand Soleil (Cantiere del Pardo) | ||
| Designer | German Frers | ||
| First built | 1988 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
