The Grinde is a 26.9ft masthead sloop designed by Peter Bruun and built in fiberglass between 1974 and 1989.
580 units have been built.
The Grinde is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Grinde | ||
| Length | 26.90 ft | ||
| Beam | 10.24 ft | ||
| Draft | 5.58 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.83 | ||
| Ballast / displ. | 45.71 % | ||
| Displ. / length | 222.32 | ||
| Comfort ratio | 21.08 | ||
| Capsize | 2.08 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 24.93 ft | ||
| Maximum draft | 5.58 ft | ||
| Displacement | 7716 lbs | ||
| Ballast | 3527 lbs | ||
| Hull speed | 6.69 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 385 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 224.04 sq.ft | ||
| Sail area main | 161.43 sq.ft | ||
| I | 36.91 ft | ||
| J | 12.14 ft | ||
| P | 32.81 ft | ||
| E | 9.84 ft |
Engine
| Nb engines | 1 | ||
| Total power | 10 HP | ||
| Fuel capacity | 8 gals |
Accommodations
| Water capacity | 24 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Peter Bruun | ||
| First built | 1974 | ||
| Last built | 1989 | ||
| Number built | 580 |
Other photos
