The Athena 34 is a 34.61ft fractional sloop designed by Håkan Södergren and built in fiberglass by Helmsman Yachts between 1980 and 1985.
70 units have been built.
The Athena 34 is a moderate weight sailboat which is a good performer. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Athena 34 | ||
| Length | 34.61 ft | ||
| Beam | 9.45 ft | ||
| Draft | 5.91 ft | ||
| Country | Denmark (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.11 | ||
| Ballast / displ. | 43.67 % | ||
| Displ. / length | 222.86 | ||
| Comfort ratio | 27.32 | ||
| Capsize | 1.73 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 27.56 ft | ||
| Maximum draft | 5.91 ft | ||
| Displacement | 10450 lbs | ||
| Ballast | 4564 lbs | ||
| Hull speed | 7.03 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 539 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 245.18 sq.ft | ||
| Sail area main | 293.86 sq.ft | ||
| I | 38.55 ft | ||
| J | 12.72 ft | ||
| P | 42.65 ft | ||
| E | 13.78 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Helmsman Yachts | ||
| Designer | Håkan Södergren | ||
| First built | 1980 | ||
| Last built | 1985 | ||
| Number built | 70 |
