The Hunter 23 is a 23.25ft fractional sloop designed by Hunter Marine and built in fiberglass by Hunter Marine (USA) between 1985 and 1992.
The Hunter 23 is a light sailboat which is a high performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Hunter 23 | ||
| Length | 23.25 ft | ||
| Beam | 8 ft | ||
| Draft | 2.25 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 20.83 | ||
| Ballast / displ. | 32.65 % | ||
| Displ. / length | 145.71 | ||
| Comfort ratio | 11.47 | ||
| Capsize | 2.38 |
Hull
| Hull type | Monohull wing keel | ||
| Construction | Fiberglass | ||
| Waterline length | 19.58 ft | ||
| Maximum draft | 2.25 ft | ||
| Displacement | 2450 lbs | ||
| Ballast | 800 lbs | ||
| Hull speed | 5.93 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 236 sq.ft | ||
| Air draft | 33 ft | ||
| Sail area fore | 110.50 sq.ft | ||
| Sail area main | 125.14 sq.ft | ||
| I | 26 ft | ||
| J | 8.50 ft | ||
| P | 25.67 ft | ||
| E | 9.75 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hunter Marine (USA) | ||
| Designer | Hunter Marine | ||
| First built | 1985 | ||
| Last built | 1992 | ||
| Number built | 0 | ?? |
