The Hunter 340 is a 33.75ft b&r designed by Hunter Design Team and built in fiberglass by Hunter Marine (USA) since 1997.
The Hunter 340 is a moderate weight sailboat which is a very high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a fast cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Hunter 340 | ||
| Length | 33.75 ft | ||
| Beam | 11.67 ft | ||
| Draft | 4.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 22.10 | ||
| Ballast / displ. | 37.17 % | ||
| Displ. / length | 210.93 | ||
| Comfort ratio | 21.45 | ||
| Capsize | 2.10 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 28.58 ft | ||
| Maximum draft | 4.50 ft | ||
| Displacement | 11030 lbs | ||
| Ballast | 4100 lbs | ||
| Hull speed | 7.16 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | B&R | ||
| Sail area (100%) | 682 sq.ft | ||
| Air draft | 55.75 ft | ||
| Sail area fore | 247.25 sq.ft | ||
| Sail area main | 352 sq.ft | ||
| I | 43 ft | ||
| J | 11.50 ft | ||
| P | 44 ft | ||
| E | 16 ft |
Engine
| Nb engines | 1 | ||
| Total power | 27 HP | ||
| Fuel capacity | 30 gals |
Accommodations
| Water capacity | 75 gals | ||
| Headroom | 6.33 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hunter Marine (USA) | ||
| Designer | Hunter Design Team | ||
| First built | 1997 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
