The Abbott 33 is a 33.29ft fractional sloop designed by Jan Larsen/Abbott and built in fiberglass by Abbott Boats Inc. since 1980.
40 units have been built.
The Abbott 33 is a light sailboat which is a high performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a racing boat. There is a very short water supply range.
Main features
| Model | Abbott 33 | ||
| Length | 33.29 ft | ||
| Beam | 8.21 ft | ||
| Draft | 5.42 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 20.84 | ||
| Ballast / displ. | 54.55 % | ||
| Displ. / length | 138.61 | ||
| Comfort ratio | 19.65 | ||
| Capsize | 1.80 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 26.92 ft | ||
| Maximum draft | 5.42 ft | ||
| Displacement | 6057 lbs | ||
| Ballast | 3304 lbs | ||
| Hull speed | 6.95 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 432 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 207 sq.ft | ||
| Sail area main | 224.55 sq.ft | ||
| I | 36 ft | ||
| J | 11.50 ft | ||
| P | 38.55 ft | ||
| E | 11.65 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 15 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Abbott Boats Inc. | ||
| Designer | Jan Larsen/Abbott | ||
| First built | 1980 | ||
| Last built | 0 | ?? | |
| Number built | 40 |
