The Invicta 26 is a 26.44ft masthead sloop designed by E. G. van de Stadt and built in fiberglass by Tyler Boat Co. Ltd. (UK) since 1964.
The Invicta 26 is a moderate weight sailboat which is a high performer. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a fast cruiser.
Main features
| Model | Invicta 26 | ||
| Length | 26.44 ft | ||
| Beam | 7.35 ft | ||
| Draft | 3.94 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 20.02 | ||
| Ballast / displ. | 45.07 % | ||
| Displ. / length | 259.68 | ||
| Comfort ratio | 24.85 | ||
| Capsize | 1.71 |
Hull
| Hull type | Monohull long keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 20.67 ft | ||
| Maximum draft | 3.94 ft | ||
| Displacement | 5137 lbs | ||
| Ballast | 2315 lbs | ||
| Hull speed | 6.09 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 371.35 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 10 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Tyler Boat Co. Ltd. (UK) | ||
| Designer | E. G. van de Stadt | ||
| First built | 1964 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
