The Avance 245 is a 24.54ft fractional sloop designed by Peter Norlin and built in fiberglass by Avance Yachts since 1972.
The Avance 245 is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Avance 245 | ||
| Length | 24.54 ft | ||
| Beam | 8.33 ft | ||
| Draft | 4.67 ft | ||
| Country | Finland (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.23 | ||
| Ballast / displ. | 48.57 % | ||
| Displ. / length | 225.96 | ||
| Comfort ratio | 16.75 | ||
| Capsize | 2.13 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 19.68 ft | ||
| Maximum draft | 4.67 ft | ||
| Displacement | 3858 lbs | ||
| Ballast | 1874 lbs | ||
| Hull speed | 5.94 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 233 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 119.49 sq.ft | ||
| Sail area main | 114 sq.ft | ||
| I | 27.50 ft | ||
| J | 8.69 ft | ||
| P | 28.50 ft | ||
| E | 8 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Avance Yachts | ||
| Designer | Peter Norlin | ||
| First built | 1972 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
