The Islander 33 is a 32.58ft masthead sloop designed by J. H. McGlasson and built in fiberglass by Islander / Tradewind Yachts between 1964 and 1971.
The Islander 33 is a heavy sailboat which is slightly under powered. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Islander 33 | ||
| Length | 32.58 ft | ||
| Beam | 10.16 ft | ||
| Draft | 4.50 ft | ||
| Country | The Nederlands (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.50 | ||
| Ballast / displ. | 33 % | ||
| Displ. / length | 322.94 | ||
| Comfort ratio | 26.51 | ||
| Capsize | 1.89 |
Hull
| Hull type | Monohull fin keel | ||
| Construction | Fiberglass | ||
| Waterline length | 24 ft | ||
| Maximum draft | 4.50 ft | ||
| Displacement | 10000 lbs | ||
| Ballast | 3300 lbs | ||
| Hull speed | 6.56 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 448 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 230 sq.ft | ||
| Sail area main | 218.03 sq.ft | ||
| I | 36.80 ft | ||
| J | 12.50 ft | ||
| P | 32.30 ft | ||
| E | 13.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Islander / Tradewind Yachts | ||
| Designer | J. H. McGlasson | ||
| First built | 1964 | ||
| Last built | 1971 | ||
| Number built | 0 | ?? |
