The Kolibri 560 is a 18.37ft masthead sloop designed by G. Pfeiffer and built in plywood or fiberglass by Kolibri Jachtbouw between 1964 and 2011.
1000 units have been built.
The Kolibri 560 is a light sailboat which is a good performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Kolibri 560 | ||
| Length | 18.37 ft | ||
| Beam | 6.89 ft | ||
| Draft | 3.28 ft | ||
| Country | The Nederlands (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.47 | ||
| Ballast / displ. | 34 % | ||
| Displ. / length | 167.30 | ||
| Comfort ratio | 11.49 | ||
| Capsize | 2.33 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Plywood or fiberglass | ||
| Waterline length | 16.40 ft | ||
| Maximum draft | 3.28 ft | ||
| Displacement | 1653 lbs | ||
| Ballast | 562 lbs | ||
| Hull speed | 5.43 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 161 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Kolibri Jachtbouw | ||
| Designer | G. Pfeiffer | ||
| First built | 1964 | ||
| Last built | 2011 | ||
| Number built | 1000 |
