The Konsort 29 westerly is a 28.83ft masthead sloop designed by Laurent Giles and partners ltd and built in fiberglass by Westerly Marine Construction Ltd. between 1979 and 1991.
704 units have been built.
The Konsort 29 westerly is a moderate weight sailboat which is slightly under powered. It is stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a short water supply range.
Main features
| Model | Konsort 29 westerly | ||
| Length | 28.83 ft | ||
| Beam | 10.75 ft | ||
| Draft | 5.33 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.05 | ||
| Ballast / displ. | 37.58 % | ||
| Displ. / length | 229.28 | ||
| Comfort ratio | 21 | ||
| Capsize | 2.11 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 25.50 ft | ||
| Maximum draft | 5.33 ft | ||
| Displacement | 8516 lbs | ||
| Ballast | 3200 lbs | ||
| Hull speed | 6.77 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 391 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 210.94 sq.ft | ||
| Sail area main | 179.98 sq.ft | ||
| I | 37.50 ft | ||
| J | 11.25 ft | ||
| P | 31.30 ft | ||
| E | 11.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 20 HP | ||
| Fuel capacity | 18 gals |
Accommodations
| Water capacity | 40 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Westerly Marine Construction Ltd. | ||
| Designer | Laurent Giles and partners ltd | ||
| First built | 1979 | ||
| Last built | 1991 | ||
| Number built | 704 |
