The Landmark 43 is a 42.98ft fractional sloop designed by M.Mills and built in carbon fiber or composite by Premier Composite Technologies since 2008.
The Landmark 43 is a light sailboat which is a very high performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a fast cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Landmark 43 | ||
| Length | 42.98 ft | ||
| Beam | 12.57 ft | ||
| Draft | 9.19 ft | ||
| Country | Emirates (Middle East) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 24.35 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 155.23 | ||
| Comfort ratio | 24.01 | ||
| Capsize | 1.94 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Carbon fiber or composite | ||
| Waterline length | 36.94 ft | ||
| Maximum draft | 9.19 ft | ||
| Displacement | 17527 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 8.14 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 1023 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 448.25 sq.ft | ||
| Sail area main | 574.32 sq.ft | ||
| I | 56.92 ft | ||
| J | 15.75 ft | ||
| P | 56.92 ft | ||
| E | 20.18 ft |
Engine
| Nb engines | 1 | ||
| Total power | 40 HP | ||
| Fuel capacity | 45 gals |
Accommodations
| Water capacity | 90 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Premier Composite Technologies | ||
| Designer | M.Mills | ||
| First built | 2008 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
