The Luders 33 allied is a 33.0ft masthead sloop designed by Bill Luders and built in fiberglass by Allied Boat Company Inc. (USA) between 1966 and 1974.
107 units have been built.
The Luders 33 allied is a very heavy sailboat which is slightly under powered. It is stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Luders 33 allied | ||
| Length | 33 ft | ||
| Beam | 10 ft | ||
| Draft | 5 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.38 | ||
| Ballast / displ. | 35.16 % | ||
| Displ. / length | 413.36 | ||
| Comfort ratio | 34.50 | ||
| Capsize | 1.71 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 24 ft | ||
| Maximum draft | 5 ft | ||
| Displacement | 12800 lbs | ||
| Ballast | 4500 lbs | ||
| Hull speed | 6.56 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 524 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 260 sq.ft | ||
| Sail area main | 264.48 sq.ft | ||
| I | 40 ft | ||
| J | 13 ft | ||
| P | 34.80 ft | ||
| E | 15.20 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 30 gals |
Accommodations
| Water capacity | 45 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Allied Boat Company Inc. (USA) | ||
| Designer | Bill Luders | ||
| First built | 1966 | ||
| Last built | 1974 | ||
| Number built | 107 |
