The M52 morris is a 52.92ft fractional sloop designed by Sparkman & Stephens and built in carbon fiber or composite by Morris Yachts since 2009.
The M52 morris is a moderate weight sailboat which is a high performer. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a fast cruiser. The fuel capacity is average. There is a good water supply range.
Main features
| Model | M52 morris | ||
| Length | 52.92 ft | ||
| Beam | 14 ft | ||
| Draft | 6.67 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 21.62 | ||
| Ballast / displ. | 33.44 % | ||
| Displ. / length | 273.45 | ||
| Comfort ratio | 36.79 | ||
| Capsize | 1.73 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Carbon fiber or composite | ||
| Waterline length | 38.17 ft | ||
| Maximum draft | 6.67 ft | ||
| Displacement | 34064 lbs | ||
| Ballast | 11391 lbs | ||
| Hull speed | 8.28 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 1414 sq.ft | ||
| Air draft | 81 ft | ||
| Sail area fore | 581.41 sq.ft | ||
| Sail area main | 784.40 sq.ft | ||
| I | 61.33 ft | ||
| J | 18.96 ft | ||
| P | 64.48 ft | ||
| E | 24.33 ft |
Engine
| Nb engines | 1 | ||
| Total power | 75 HP | ||
| Fuel capacity | 80 gals |
Accommodations
| Water capacity | 100 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Morris Yachts | ||
| Designer | Sparkman & Stephens | ||
| First built | 2009 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
