The Macgregor 26x is a 25.82ft fractional sloop designed by Roger MacGregor and built in fiberglass by Macgregor Yacht Corp between 1995 and 2003.
5000 units have been built.
The Macgregor 26x is a light sailboat which is a good performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Macgregor 26x | ||
| Length | 25.82 ft | ||
| Beam | 7.83 ft | ||
| Draft | 0.75 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.68 | ||
| Ballast / displ. | 37.33 % | ||
| Displ. / length | 137.59 | ||
| Comfort ratio | 15.67 | ||
| Capsize | 2.02 |
Hull
| Hull type | Monohull centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 23 ft | ||
| Maximum draft | 5.50 ft | ||
| Displacement | 3750 lbs | ||
| Ballast | 1400 lbs | ||
| Hull speed | 6.43 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 281 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 111.21 sq.ft | ||
| Sail area main | 129.75 sq.ft | ||
| I | 23 ft | ||
| J | 9.67 ft | ||
| P | 25 ft | ||
| E | 10.38 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 18 gals |
Accommodations
| Water capacity | 10 gals | ||
| Headroom | 5.92 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Macgregor Yacht Corp | ||
| Designer | Roger MacGregor | ||
| First built | 1995 | ||
| Last built | 2003 | ||
| Number built | 5000 |
