The Mahe 36 is a 36.19ft fractional sloop designed by Joubert - Nivelt / Flahault and built in fiberglass by Fountaine Pajot since 2004.
The Mahe 36 is a light sailboat which is a very high performer. The fuel capacity is average. There is a short water supply range.
Main features
| Model | Mahe 36 | ||
| Length | 36.19 ft | ||
| Beam | 19.41 ft | ||
| Draft | 3.62 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 22.69 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 114.78 | ||
| Comfort ratio | 9.29 | ||
| Capsize | 3.49 |
Hull
| Hull type | Catamaran Twin Keel | ||
| Construction | Fiberglass | ||
| Waterline length | 35 ft | ||
| Maximum draft | 3.62 ft | ||
| Displacement | 11023 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 7.93 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 700 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 55 gals |
Accommodations
| Water capacity | 71 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Fountaine Pajot | ||
| Designer | Joubert - Nivelt / Flahault | ||
| First built | 2004 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
