The Malabar sr alden is a 33.25ft masthead sloop designed by John G. Alden and built in wood by LeComte Yachts between 1956 and 1963.
24 units have been built.
The Malabar sr alden is a very heavy sailboat which is slightly under powered. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is originally small. There is a very short water supply range.
Main features
| Model | Malabar sr alden | ||
| Length | 33.25 ft | ||
| Beam | 9.75 ft | ||
| Draft | 5 ft | ||
| Country | The Nederlands (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.52 | ||
| Ballast / displ. | 31.82 % | ||
| Displ. / length | 417.35 | ||
| Comfort ratio | 36.53 | ||
| Capsize | 1.65 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Wood | ||
| Waterline length | 24.17 ft | ||
| Maximum draft | 5 ft | ||
| Displacement | 13200 lbs | ||
| Ballast | 4200 lbs | ||
| Hull speed | 6.59 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 505 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 260.05 sq.ft | ||
| Sail area main | 295.85 sq.ft | ||
| I | 40.92 ft | ||
| J | 12.71 ft | ||
| P | 35.86 ft | ||
| E | 16.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 25 HP | ||
| Fuel capacity | 30 gals |
Accommodations
| Water capacity | 35 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | LeComte Yachts | ||
| Designer | John G. Alden | ||
| First built | 1956 | ||
| Last built | 1963 | ||
| Number built | 24 |
