Mayflower 48stadel 48
excluded / 112 - score 0%
It looks like this boat is not adapted to your usage.
The Mayflower 48stadel 48 is a 48.0ft masthead ketch designed by George Stadel Jr. and built in fiberglass between 1979 and 1984.
42 units have been built.
The Mayflower 48stadel 48 is a moderate weight sailboat which is slightly under powered. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a heavy bluewater cruising boat.
Main features
| Model | Mayflower 48stadel 48 | ||
| Length | 48 ft | ||
| Beam | 13.50 ft | ||
| Draft | 5.67 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.27 | ||
| Ballast / displ. | 33.78 % | ||
| Displ. / length | 274.85 | ||
| Comfort ratio | 42.71 | ||
| Capsize | 1.62 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 39.17 ft | ||
| Maximum draft | 5.67 ft | ||
| Displacement | 37000 lbs | ||
| Ballast | 12500 lbs | ||
| Hull speed | 8.39 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Ketch | ||
| Sail area (100%) | 1055 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 458.60 sq.ft | ||
| Sail area main | 392 sq.ft | ||
| I | 53.70 ft | ||
| J | 17.08 ft | ||
| P | 49 ft | ||
| E | 16 ft |
Engine
| Nb engines | 1 | ||
| Total power | 85 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | George Stadel Jr. | ||
| First built | 1979 | ||
| Last built | 1984 | ||
| Number built | 42 |
