The Mirage 29 is a 29.0ft masthead sloop designed by Philippe Harlé and built in fiberglass by Mirage Yachts Ltd (CAN) since 1986.
290 units have been built.
The Mirage 29 is a moderate weight sailboat which is a reasonably good performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Mirage 29 | ||
| Length | 29 ft | ||
| Beam | 10.50 ft | ||
| Draft | 4.83 ft | ||
| Country | Canada (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.89 | ||
| Ballast / displ. | 33.82 % | ||
| Displ. / length | 212.88 | ||
| Comfort ratio | 17.86 | ||
| Capsize | 2.22 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 24.25 ft | ||
| Maximum draft | 4.83 ft | ||
| Displacement | 6800 lbs | ||
| Ballast | 2300 lbs | ||
| Hull speed | 6.60 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 400 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 220.66 sq.ft | ||
| Sail area main | 154.38 sq.ft | ||
| I | 37.40 ft | ||
| J | 11.80 ft | ||
| P | 32.50 ft | ||
| E | 9.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 18 HP | ||
| Fuel capacity | 10 gals |
Accommodations
| Water capacity | 10 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Mirage Yachts Ltd (CAN) | ||
| Designer | Philippe Harlé | ||
| First built | 1986 | ||
| Last built | 0 | ?? | |
| Number built | 290 |
