The Mustang 30 is a 29.53ft fractional sloop designed by Paul Handley and built in fiberglass by Harley Race Boats between 1988 and 1998.
29 units have been built.
The Mustang 30 is a moderate weight sailboat which is under powered. It is not stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Mustang 30 | ||
| Length | 29.53 ft | ||
| Beam | 8.14 ft | ||
| Draft | 5.61 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 0 | ?? | |
| Ballast / displ. | 0 % | ||
| Displ. / length | 204.92 | ||
| Comfort ratio | 21.67 | ||
| Capsize | 1.82 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 23.23 ft | ||
| Maximum draft | 5.61 ft | ||
| Displacement | 5754 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 6.46 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 0 sq.ft | ?? | |
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 10 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Harley Race Boats | ||
| Designer | Paul Handley | ||
| First built | 1988 | ||
| Last built | 1998 | ||
| Number built | 29 |
