The Nord 80 is a 26.18ft masthead sloop designed by Olle Enderlain and built in fiberglass since 1975.
260 units have been built.
The Nord 80 is a moderate weight sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Nord 80 | ||
| Length | 26.18 ft | ||
| Beam | 9.19 ft | ||
| Draft | 4.43 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.03 | ||
| Ballast / displ. | 45.83 % | ||
| Displ. / length | 267.47 | ||
| Comfort ratio | 19.08 | ||
| Capsize | 2.11 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 20.67 ft | ||
| Maximum draft | 4.43 ft | ||
| Displacement | 5291 lbs | ||
| Ballast | 2425 lbs | ||
| Hull speed | 6.09 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 360 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 11 gals |
Accommodations
| Water capacity | 17 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Olle Enderlain | ||
| First built | 1975 | ||
| Last built | 0 | ?? | |
| Number built | 260 |
