The Nova 33 albin is a 33.0ft fractional sloop designed by Peter Norlin and built in fiberglass by Albin Marine between 1981 and 1997.
500 units have been built.
The Nova 33 albin is a moderate weight sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Nova 33 albin | ||
| Length | 33 ft | ||
| Beam | 10.33 ft | ||
| Draft | 5.50 ft | ||
| Country | Sweden (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.50 | ||
| Ballast / displ. | 47.30 % | ||
| Displ. / length | 201.82 | ||
| Comfort ratio | 19.93 | ||
| Capsize | 2.05 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 26.25 ft | ||
| Maximum draft | 5.50 ft | ||
| Displacement | 8177 lbs | ||
| Ballast | 3868 lbs | ||
| Hull speed | 6.87 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 493 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 213.06 sq.ft | ||
| Sail area main | 279.89 sq.ft | ||
| I | 35.10 ft | ||
| J | 12.14 ft | ||
| P | 39.70 ft | ||
| E | 14.10 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 12 gals |
Accommodations
| Water capacity | 23 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Albin Marine | ||
| Designer | Peter Norlin | ||
| First built | 1981 | ||
| Last built | 1997 | ||
| Number built | 500 |
