The O'day 23 1 lift top is a 23.0ft masthead sloop designed by C. Raymond Hunt Assoc. and built in fiberglass by O'Day Corp. since 1972.
The O'day 23 1 lift top is a light sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | O'day 23 1 lift top | ||
| Length | 23 ft | ||
| Beam | 7.93 ft | ||
| Draft | 2 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.49 | ||
| Ballast / displ. | 40.32 % | ||
| Displ. / length | 172.99 | ||
| Comfort ratio | 14.53 | ||
| Capsize | 2.18 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 20 ft | ||
| Maximum draft | 5.40 ft | ||
| Displacement | 3100 lbs | ||
| Ballast | 1250 lbs | ||
| Hull speed | 5.99 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 245 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 133.44 sq.ft | ||
| Sail area main | 111.60 sq.ft | ||
| I | 27.80 ft | ||
| J | 9.60 ft | ||
| P | 24 ft | ||
| E | 9.30 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | O'Day Corp. | ||
| Designer | C. Raymond Hunt Assoc. | ||
| First built | 1972 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
