The O'day 322 is a 32.08ft masthead sloop designed by C. Raymond Hunt Associates and built in fiberglass by O'Day Corp. between 1986 and 1989.
228 units have been built.
The O'day 322 is a moderate weight sailboat which is slightly under powered. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a short water supply range.
Main features
| Model | O'day 322 | ||
| Length | 32.08 ft | ||
| Beam | 10.67 ft | ||
| Draft | 4.16 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.79 | ||
| Ballast / displ. | 34.44 % | ||
| Displ. / length | 241.22 | ||
| Comfort ratio | 23.92 | ||
| Capsize | 1.97 |
Hull
| Hull type | Monohull wing keel | ||
| Construction | Fiberglass | ||
| Waterline length | 26.67 ft | ||
| Maximum draft | 4.16 ft | ||
| Displacement | 10250 lbs | ||
| Ballast | 3530 lbs | ||
| Hull speed | 6.92 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 464 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 235.81 sq.ft | ||
| Sail area main | 228.59 sq.ft | ||
| I | 38.50 ft | ||
| J | 12.25 ft | ||
| P | 33.25 ft | ||
| E | 13.75 ft |
Engine
| Nb engines | 1 | ||
| Total power | 18 HP | ||
| Fuel capacity | 19 gals |
Accommodations
| Water capacity | 60 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | O'Day Corp. | ||
| Designer | C. Raymond Hunt Associates | ||
| First built | 1986 | ||
| Last built | 1989 | ||
| Number built | 228 |
