The O'day 35 is a 35.0ft masthead sloop designed by C. R. Hunt Assoc. and built in fiberglass by O'Day Corp. between 1984 and 1989.
The O'day 35 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a very short water supply range.
Main features
| Model | O'day 35 | ||
| Length | 35 ft | ||
| Beam | 11.25 ft | ||
| Draft | 5.58 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.51 | ||
| Ballast / displ. | 40 % | ||
| Displ. / length | 216.04 | ||
| Comfort ratio | 23.10 | ||
| Capsize | 2 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 28.75 ft | ||
| Maximum draft | 5.58 ft | ||
| Displacement | 11500 lbs | ||
| Ballast | 4600 lbs | ||
| Hull speed | 7.18 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 524 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 301 sq.ft | ||
| Sail area main | 223.25 sq.ft | ||
| I | 43 ft | ||
| J | 14 ft | ||
| P | 38 ft | ||
| E | 11.75 ft |
Engine
| Nb engines | 1 | ||
| Total power | 21 HP | ||
| Fuel capacity | 50 gals |
Accommodations
| Water capacity | 30 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | O'Day Corp. | ||
| Designer | C. R. Hunt Assoc. | ||
| First built | 1984 | ||
| Last built | 1989 | ||
| Number built | 0 | ?? |
