The Bavaria cruiser 34 is a 35.14ft fractional sloop designed by J & J Design and built in fiberglass by Bavaria Yachts (GER) since 2000.
The Bavaria cruiser 34 is a moderate weight sailboat which is a good performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Bavaria cruiser 34 | ||
| Length | 35.14 ft | ||
| Beam | 11.81 ft | ||
| Draft | 6.33 ft | ||
| Country | Germany (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.58 | ||
| Ballast / displ. | 24.56 % | ||
| Displ. / length | 204.08 | ||
| Comfort ratio | 22.89 | ||
| Capsize | 2.04 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 30.18 ft | ||
| Maximum draft | 6.33 ft | ||
| Displacement | 12566 lbs | ||
| Ballast | 3086 lbs | ||
| Hull speed | 7.36 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 659 sq.ft | ||
| Air draft | 48.69 ft | ||
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 28 HP | ||
| Fuel capacity | 40 gals |
Accommodations
| Water capacity | 55 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Bavaria Yachts (GER) | ||
| Designer | J & J Design | ||
| First built | 2000 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
