The Oceanis yacht 54 Beneteau is a 56.17ft fractional sloop designed by Biscontini Yacht Design and built in fiberglass by Beneteau since 2020.
The Oceanis yacht 54 Beneteau is a light sailboat which is a reasonably good performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is good. There is a good water supply range.
Main features
| Model | Oceanis yacht 54 Beneteau | ||
| Length | 56.17 ft | ||
| Beam | 16.40 ft | ||
| Draft | 8.20 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.89 | ||
| Ballast / displ. | 27.11 % | ||
| Displ. / length | 126.71 | ||
| Comfort ratio | 26.12 | ||
| Capsize | 1.98 |
Hull
| Hull type | Monohull fin keel with bulb and dual rudders | ||
| Construction | Fiberglass | ||
| Waterline length | 50.52 ft | ||
| Maximum draft | 8.20 ft | ||
| Displacement | 36597 lbs | ||
| Ballast | 9921 lbs | ||
| Hull speed | 9.52 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 1227.09 sq.ft | ||
| Air draft | 78.74 ft | ||
| Sail area fore | 728.31 sq.ft | ||
| Sail area main | 731.99 sq.ft | ||
| I | 65.29 ft | ||
| J | 22.31 ft | ||
| P | 65.62 ft | ||
| E | 22.31 ft |
Engine
| Nb engines | 1 | ||
| Total power | 80 HP | ||
| Fuel capacity | 106 gals |
Accommodations
| Water capacity | 190 gals | ||
| Headroom | 6.50 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Beneteau | ||
| Designer | Biscontini Yacht Design | ||
| First built | 2020 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
