Bavaria cruiser 40s farr
excluded / 26 - score 0%
It looks like this boat is not adapted to your usage.
The Bavaria cruiser 40s farr is a 40.52ft fractional sloop designed by Farr Yacht Design and built in fiberglass by Bavaria Yachts (GER) since 2011.
The Bavaria cruiser 40s farr is a light sailboat which is a good performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a short water supply range.
Main features
| Model | Bavaria cruiser 40s farr | ||
| Length | 40.52 ft | ||
| Beam | 12.96 ft | ||
| Draft | 7.55 ft | ||
| Country | Germany (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.70 | ||
| Ballast / displ. | 33.61 % | ||
| Displ. / length | 182.59 | ||
| Comfort ratio | 24.82 | ||
| Capsize | 1.98 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 35.27 ft | ||
| Maximum draft | 7.55 ft | ||
| Displacement | 17945 lbs | ||
| Ballast | 6032 lbs | ||
| Hull speed | 7.96 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 841 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 359.42 sq.ft | ||
| Sail area main | 481.33 sq.ft | ||
| I | 51.94 ft | ||
| J | 13.84 ft | ||
| P | 51.84 ft | ||
| E | 18.57 ft |
Engine
| Nb engines | 1 | ||
| Total power | 28 HP | ||
| Fuel capacity | 55 gals |
Accommodations
| Water capacity | 55 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Bavaria Yachts (GER) | ||
| Designer | Farr Yacht Design | ||
| First built | 2011 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
